Mini 00B 2/3/4pin circular connector for audio application


EX-PRO 00B mini 2/3/4pin connector can be mainly applied in Audio/Video instrument like lastest famouse sennheiser HD800 OR 3000

Type: Mini circular connector

Application: Audio&Video

Gender: Male

No. of pin: 2/3/4/pin

Insulator material: PPS

Endurance: 5000 mating circles

Shell material: Chrome-plated,Brass alloy

Contact material: Gold-plated,Brass alloy

Temperature range: -45 deg C, +125 deg C

EX-PRO's high quality push-pull self-locking connectors are found in a variety of challenging application environments including medical, mechanical equipment, audio / video, test and measurement, communications, automotive and power, and other fields.

* Main features:

1-The quick push-pull self-locking system

2-Welding, crimping, and printing board connector

3-Straight, elbow.

4-Multiple keys options to avoid cross mating of similar connectors.

5- 360° screening for full EMC shielding

6-Series of multi-core, high-density installation space-saving

7-Key system pins standard for connector alignment.
