Type:Mini circular connector
NO.of Pin:2/3/4pin
Connector panel size:7mm
Connector material: Gold-plated,Brass alloy
Cureent rating:5.0A
Application:Audio&Video
Insulator material:PPS
Contact diameter:0.5mm
Temperature range:-45 degC,+125degC
Model Number:YGG.00B.02/03/04.CLAD
Gender:Male
Endurance:5000 mating circles
Shell material: Chrome-plated,Brass alloy
Working voltage:900V/DC,600V/AC
IP Rating: IP60
Endurance: >5000 mating circles

Main features:
1-2pin cable plug connector,
2-Welding,crimping,and printing board connector
3-Straight,elbow.
4-Multiple keys options to avoid cross mating of similar connectors
5-360°screening for full EMC shielding
6-Series of multi-core,high-density installation space-saving
7-Key system pins standard for connector alignment
